Main features
Multiple Utility Design
An attenuverter, offset generator, crossfader and attenuator all in a single compact module
Flexible Signal Control
Attenuverter section allows for precise gain and polarity adjustments, as well as DC offset generation
Standalone CV Source
Generates control voltages from −5V to +5V when no input is connected
Versatile Crossfading
Smoothly fades between two input signals, suitable for both audio and CV applications
Top-quality audio & CV
Use of Texas Instruments© active components allow for clean and precise signal processing
Configurable Gain Settings
Selectable attenuverter gain ranges (Unity, 3x, 10x) via onboard jumper to match various signal levels
Normalization Options
Input A of the crossfader can be normalized to +5V, −5V, or the offset voltage via onboard jumper
Compact design
At just 2HP, the module will easily find its spot in any Eurorack setup
